Pioneer GM-D8604 – 4-Channel Class FD Car Amplifier With 1200 Watts Max Power & Compact Design

$250.00 $199.00

The Pioneer GM-D9605 Class D 5 Channel car amplifier has upped the standard when it comes to power, build quality, and listening excellence… (see full description)

Extended Warranty

SKU: GM-D8604 Categories: ,


The Pioneer GM-D8604 Class FD 4-Channel Bridgeable car amplifier is an excellent purchase if you’re looking to step up your car audio by several notches, and this amp will certainly give you the punch you’re looking for in a nice compact design.


In general, you can expect this amplifier to send around 100 W RMS to every one of your speakers, so you’ll really notice the power that your current system is able to produce when you install this beast of an amplifier.

Efficient Class D Technology

While many amps like these are known to be power hogs, this one benefits from the efficient class D technology that keeps it running surprisingly cool, and the compact size means that you won’t have too much trouble when it comes to installation either.

It’s worth noting that you can incorporate this system into many different setups, both large and small, and its versatility is a large reason why many people choose this particular model from the well-respected Pioneer brand.

Final Thoughts

One of the best ways to run this system is to hook it up with a mono amp to drive your subs while using this to run your other speakers, but the amp can equally serve well in any other setup you choose.

Lastly, the Pioneer GM-D8604 comes with some useful features such as the variable high and low pass filter that give you some extra control over your playback, which makes this a very attractive amplifier.

$250.00 $199.00Add to cart

Additional information

Amplifier Specifications:

See Below

Amplifier Series

GM Digital (Pioneer)

Amplifier Class

Class FD

Number of Channels


Total Peak Power Output

1,200 watts

Total RMS Power Output

600 watts

Maximum Input Gauge Size


Minimum Impedance Unbridged

1 ohms

Minimum Impedance Bridged

4 ohms

THD at Rated RMS Power


Speaker Level Inputs


Preamp Outputs


Built-in Crossover

Low-Pass (LP)
High-Pass (HP)

High-Pass Crossover Frequency

40 – 500 Hz

Low-Pass Crossover Frequency

40 – 500 Hz

Signal-to-Noise Ratio

95 dB

Bass/Gain Remote


Fan Cooled


Fuse Rating

30A x 2



CEA-2006 Compliant


RMS Power @ 4 ohms

100 watts x 4 channels

RMS Power @ 2 ohms

150 watts x 4 channels

RMS Power @ 1 ohm

125 watts x 4 channels

Bridged RMS Power

300 watts x 2 channels
